Electric Oil Pumps
Proven in the field, and in production with a number of Global OEM’s, the Concentric electric Oil Pump range is used in a number of applications such as; lubrication and cooling of eMachines and eAxles, transmission stop/start, piston cooling etc. As with all Concentric ePumps, durability and reliability are designed-in, with the pump validated to >50,000 hours of continuous running. The hydraulic pump design can be tailored to meet customers specific needs. Concentric provides further flexibility through both 12V and 24V capability in the same pump, ideal for Global customers needs.
| Model | 200 Series, Performance Range |
| Construction | Cast Aluminum and PBT Resin |
| Dimensions | 5.5″ x 5.0″ x 5.0″ |
| Weight | 3.3 lbs |
| Flow Capacity | Up to 5.5 GPM |
| Maximum Pressure | Up to116 PSI |
| Voltage | 9-32 VDC |
| Control | On/Off CAN J1939 |
| Model | 200 Series, Performance Range |
| Construction | Cast Aluminum and PBT Resin |
| Dimensions | 140mm x 130mm x 130mm |
| Weight | 1.5 kg |
| Flow Capacity | 21 L/m |
| Maximum Pressure | 8 Bar |
| Voltage | 9-32 VDC |
| Control | On/Off CAN J1939 |
